TA 141 Mitre Saw
| Brand | Haffner |
|---|
- For Aluminum and PVC profiles cutting
- Pneumatic sawing feed from below with 350mm diameter saw blade
- The saw blade feed speed can be adjusted via the pneumatic control
- Wide angle range from 22.5° to 112.5° with special location points at 45°, 90° & 135°
- Two hand safety operation
- Vertical pneumatic clamps ensure optimum profile fixing
- Filter-Regulator-Lubricator for incoming air supply
- Pulse spray mist blade lubricant system
- Power supply: 400V, 3ph, 50-60Hz
- Power output: 1.1 kW (2.2kW optional for aluminium)
- Saw Blade Diameter: 350mm
- Saw Blade Speed: 2,800rpm (50Hz), 3,360rpm (50Hz)
- Max profile length: 3,700mm
- Air pressure: 6-8bar
- Air consumption: 95 l/min
- Machine height: 1,300mm
- Machine length: 800mm
- Machine width: 700mm
- Machine weight: 195kg
TK-060 Support conveyor system
TK-061 3m Right hand conveyor & measuring stop
TK-062 3m Left hand conveyor & measuring stop
MS-300 Automatic measuring and positioning system
AS-021 Cooling system to cut aluminum profiles
AH-041 Hydro-pneumatic system for aluminum profiles
